The perfect tools for alignment Leica Lino L2

Avoid time consuming line drawings on walls with the use of the Leica Lino L2. This modern device projects accurate laser lines quickly and effortlessly and increases your efficiency to help you get the job done.

Advantages of the L2 Point Laser

• Power-saving mode and pulse function
• Ergonomic and stylish housing
• Precise 90° angles
• Sizeable lens
• Simple and easy to use

Dedicated for:

• Horizontal alignments
  There is no need to use a string line or spirit level again as the Leica Lino L2 quickly and easily transfers reference points across the room from one wall to another.
• Vertical alignments
  Theglass lens helps the floor and wall tile joints meet together accurately and with great ease.
• Perfect 90° angle
  With the touch of just one button, marking out alignment tasks can be done which save you time when you need it.
• Angle alignments
  With the use of the lock feature, you can manually turn off the self-levelling function. The laser beam and then be pointed and projected and angle desired angle. The lock function also provides protection when the device is being transported.
• Working in adverse light conditions
  The Pulse Function saves energy and in very bright light conditions the detector can locate the laser lines. Acoustic signals given from the laser detector show the position of the laser beam plane accurately.

• Range up to 15 metres if light conditions are favourable
• Range with the use of the detector Up to 30 metres
• Levelling accuracy at 5 metres ± 1.5 millimetres
• Range of self-levelling 4° ± 0.5°
• Plumb point @ 5 metres accuracy ± 1.5 millimetres
• Number of laser points 2
• Direction of beam Up and down
• Type of laser laser class II, 635 nm
• Batteries 3 × AA type 1.5 V
• Protection class IP54 Splash water / dust proof
• Temperature (operating) 40 °C to –10 °C
• Temperature (storage) 70 °C to –25 °C
• Dimensions (Depth × Width x Height) 91 x 54 x 96 millimetres
• Weight (no batteries) 321 grams

• Leica Lino L2 Line Laser
• Target plate
• Multifunction adapter (Magnetic)
• Ball adapter for use with tripod
• 3x AA type alkaline batteries
• Protective pouch
